723 Desert Storm Delta

$2,799.00

T723556145CP
Purchase
Made to Order
This rifle is chambered in 5.56 NATO.
Our uppers and lowers are forged from 7075-T611 aluminum.
All Short Barrel Rifles (SBR) are considered an NFA item and require a Tax Stamp. Please contact your local dealer to request info on your states laws. Please also note, that this configuration can be ordered as a pistol as well.
This platform is built on a 6R, 4150V chrome moly vanadium barrel finished in a clean Nitride finish. All 5.56 NATO barrels are threaded with a 1/2X28 pitch.
All of our Carriers go through a R.E.M Polish process prior to QPQ coating. The R.E.M Polish process reduces friction, improves part durability, improves oil retention, and improves contact & bending fatigue. Our Bolts are MPI (Magnetic Particle Inspected) and coated in a durable titanium nitride finish.
This model has been upgraded with an fully ambidextrous fire selector.
Offered with a Mil-Spec or 2-Stage Trigger

Quick Specs

CALIBER: 5.56 NATO
CLASSIFICATION: Rifle
BARREL LENGTH: 14.5 Pinned & Welded
HANDGUARD: A2 Clamshell
GAS SYSTEM: Non-Adjustable
GAS LENGTH: Carbine Length
TRIGGER: Mil-Spec Single Stage or Two-Stage
MUZZLE: A2 Bird Cage Flash Hider
BCG: QPQ W/R.E.M Polish
OVERALL LENGTH:
FIRE SELECTOR: Ambi-Short Throw Adjustable
WEIGHT:



Description

When Colt incorporated the M16A2 improvements into its carbines, the company created the “M16A2 Carbine” family. This family was mostly known for its most praised model, called the Model 723. The Colt 723  combined the simpler A1 rear sight with an A2-era case deflector as well as s 1:7 twist barrel. It kept a lightweight 14.5″ barrel for balance and speed, which is why operators loved the 723 for CQB and urban fighting.

According to Larry Vickers, his Delta Force 723 went to Panama’s Cárcel Modelo prison during Operation Acid Gambit in 1989, and later on Desert Storm SCUD-hunt missions in 1991. A real-world endorsement that echoed across SOF. Vickers’ account also links these carbines—and their early red-dot use—to the Army’s eventual M4 + Aimpoint M68 standardization. Operation Acid Gambit context: a Delta hostage-rescue at Panama City’s Modelo Prison on Dec 20, 1989, during the U.S. invasion

.By 1993, Delta operators in Operation Gothic Serpent (the “Black Hawk Down” battle) carried 723-based carbines, while many Rangers ran full-length M16A2s (and some 727s). Visual tell: A1 rear sight (723) vs A2 “drum” rear sight (727).

This TYPE-A 723 is built on an accurate Carbine platform with proven mil-spec components to make an incredibly versatile rifle. The 723 is equipped with a 14.5 5R, 4150V chrome moly vanadium barrel finished in a clean Nitride with an A2 Bird Cage Flash Hider that is pinned and welded.  Our 723 is also equipped with an A2 Clamshell & CAR-15 style furniture.  The TYPE-A 723 Rifle is driven by our TYPE-A QPQ bolt carrier group with an R.E.M. Polish. Equipped with a DGI (direct gas impingement) system and our crisp Mil-Spec Trigger to give it consistent reliability time after time.

NOTE:  All of our rifles are Hardcoat Anodized and then Cerakoted to give you a longer lasting more durable finish.  We wanted your rifle to wear to the anodized surface versus the raw aluminum surface like some of our competitors.  Just another added benefit of making our rifles…TYPE-A.

****Please Note: All NFA rules apply. Please check with your local state laws.

Features

*(OPTICS NOT INCLUDED, FLASHLIGHT IS INCLUDED)

BARREL

  • Caliber: 5.56 NATO
  • Length: 14.5″ 5R, 4150V
  • Gas block: A2 Front Sight Post
  • Material: Proprietary high-grade Chrome Moly Vanadium steel
  • Gas System: Carbine Length
  • Twist Rate: 1:7 twist
  • Finish: Magphos
  • Thread: 1/2×28
  • Muzzle Device: Options Available

UPPER RECEIVER

  • Platform:  C7 Precision Machined 7075-t6 Aluminum Upper Receiver with Extended Feed Ramps
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type-III Anodizing with Cerakote Ceramic Coatings
  • Charging Handle:  A2 Mil-Spec Charging handle
  • Bolt Carrier Group: TYPE-A QPQ W/REM POLISH BOLT CARRIER GROUP

    • Benefits:  Low Friction Coefficient (dry against steel)
    • High Service Temperature
    • All the benefits from Hard PVD Coatings
    • M16 Style Carrier
      • Billet 8620 Steel
      • Heat Treated
      • Precision Grinding on all three ID’s.
    • 5.56/.223 Bolt
      • Billet 9310 Steel
      • Heat Treated
      • Shot Peened
      • MPI Tested (Magnetic Particle Inspection)
    • Billet Gas Key
      • Billet of 4130 Steel (Use of Gasking Material)
      • Seated with Grade 8 Fasteners (Use of Anaerobic)
      • Properly Staked
    • Cam Pin
      • Billet 4140 Steel
      • Heat Treated
    • Billet Extractor
      • Billet of 4140 Steel
      • Heat Treated
      • Shot Peened
      • Coating: Phosphate (Low Heat Input)
      • Extractor Insert
      • Viton O-Ring
    • Firing Pin
      • Billet 8640 Steel

LOWER RECEIVER

  • Platform: GEN3 Precision Machined 7075-t6 Aluminum Lower Receiver
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type III Anodizing with Cerakote Ceramic Coatings
  • Trigger: Mil-Spec Trigger
  • Extension: 6-Position Adjustable Buffer Tube – Carbine Length
  • End Plate: Mil-Spec end plate
  • Fire Selector: Mil-Spec fire selector
  • Magazine Release: Mil-Spec mag release
  • Lower Parts: Stainless Steel/Aluminum Detents & Springs

HANDGUARD/RAIL

  • Platform: Option
    • A2 Clamshell
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type-III Anodizing with Cerakote Ceramic Coatings

FURNITURE

  • Stock: CAR Stock – BLK
  • Grip: A2 Grip – BLK

ACCESSORIES (INCLUDED W/RIFLE)

  • Magazine: Dual DURMAG 30 Round Steel Magazine
  • Soft Case: 36″ Single Rifle Case
  • Light Assembly: Larry Vicker’s Clone Flashlight

Colors Available (*Shown in Hardcoat Anodized Black)
