M4A1 BLOCK II

$2,099.00

TM4A1B2556145CPP
Purchase
Made to Order
556 only ICON
This rifle is chambered in 5.56 NATO.
FORGED ICON WHITE
Our uppers and lowers are forged from 7075-T611 aluminum.
WELDED ICON WHITE
Our 14.5's are pinned and welded to meet the 16" OAL (overall length) requirements. We also offer many options when it comes to suppressor ready muzzle devices. Please contact sales for all available options.
AMBI ICON WHITE
Our Pro Forged Pistols are semi-ambidextrous. They standard with a fully adjustable 90/70 degree short throw safety selector and an extended magazine release to give you that perfect feel. Our charging handle is fully Ambi giving you complete control from either side.
BCG ICON WHITE
All of our Carriers go through a R.E.M Polish process prior to coating. The R.E.M Polish process reduces friction, improves part durability, improves oil retention, and improves contact & bending fatigue. Our Bolts are MPI (Magnetic Particle Inspected) and coated in a durable Chrome Nitride Finish.
AGB ICON WHITE
This model will come standard with a 5 position adjustable gas block to give you the ability to find tune your firearm while running suppressor or even while running higher pressure rounds.
TRIGGER 5
This rifle runs our TYPE-A PMC Two-Stage Trigger. Constructed from pre-hardened 4140 this trigger is coated in QPQ to fight against friction and to ensure lubricity. The PMC Two-Stage Trigger ships at 1 1/2 reset to 3 1/2 trigger pull.

Quick Specs

CALIBER: 5.56 NATO
CLASSIFICATION: SBR or Rifle
BARREL LENGTH: 14.5″
HANDGUARD: MK Quad Rail
GAS SYSTEM: Fully Adjustable
GAS LENGTH: Carbine Length
TRIGGER: 2-Stage
MUZZLE: ASR Suppressor Ready
BCG: Chrome Nitride – Matte Finish
OVERALL LENGTH:
FIRE SELECTOR: Ambi-Short Throw Adjustable
WEIGHT:



Description

Here at TYPE-A, we are big fans of GWOT-age firearms. One of these modern classics is the M4A1 Block II which has become a modern classic. We have developed our own variant to call back on the glorious quad rails and short CQB-style firearms of the day. Being a RESTOMOD variant, we have upgraded various aspects of this firearm to make it truly a modernized classic with old-school flavor but all of the performance is expected out of firearms today.

Our CQBR Block II  is equipped with a 14.5″ Chrome-Lined, 5R, 4150V chrome moly vanadium barrel finished in a clean Mag Phos finish with an ASR suppressor-ready muzzle. The TYPE-A M4A1 Block II is driven by our TYPE-A Chrome Nitride bolt carrier group with an R.E.M Polish. Equipped with a DGI (direct gas impingement) system and our new TYPE-A PMC Straight 2-stage trigger to give it consistent reliability time after time.

NOTE:  All of our rifles are Hardcoat Anodized and then Cerakoted to give you a longer lasting more durable finish.  We wanted your rifle to wear to the anodized surface versus the raw aluminum surface like some of our competitors.  Just another added benefit of making our rifles…TYPE-A.

****Please Note: All NFA rules apply. Please check with your local state laws.

Colors Available (*Shown in Armor Black & Midnight Bronze)

  • Magpul™ Olive Drab Green (H-232Q)
  • Magpul™ Flat Dark Earth (H-267Q)
  • Noveske™ Bazooka Green (H-189Q)
  • Tungsten (H-237Q)
  • SIG™ Dark Grey (H-210Q)

Features

*(OPTICS & ACCESSORIES NOT INCLUDED)

BARREL

  • Caliber: 5.56 NATO
  • Length: TYPE-A 14.5″ 1/7 twist
  • Gas block: RS5 Improved Flow 5-Position Adjustable Gas Block
  • Material: 4150V chrome moly vanadium
  • Gas System: Carbine Length
  • Twist Rate: 5R W/1:7 twist
  • Finish: Chrome-Lined w/ Mag Phos finish
  • Thread: 1/2×28
  • Muzzle Device: Type A ASR Ready Muzzle or Other Muzzles Available For Additional Cost

UPPER RECEIVER

  • Platform:  GEN3 Precision Machined 7075-t6 Aluminum Upper Receiver with Extended Feed Ramps
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type-III Anodizing with Cerakote Ceramic Coatings
  • Charging Handle: TYPE-A Ambi Charging Handle

Bolt Carrier Group

  • Coating:  CertessTM Nitro N CrN W/REM Polish

    • Benefits:  Low Friction Coefficient (dry against steel)
    • High Service Temperature
    • All the benefits from Hard PVD Coatings
  • M16 Style Carrier
    • Billet 8620 Steel
    • Heat Treated
    • Precision Grinding on all three ID’s.
  • 5.56/.223 Bolt
    • Billet 9310 Steel
    • Heat Treated
    • Shot Peened
    • MPI Tested (Magnetic Particle Inspection)
  • Billet Gas Key
    • Billet of 4130 Steel (Use of Gasking Material)
    • Seated with Grade 8 Fasteners (Use of Anaerobic)
    • Properly Staked
  • Cam Pin
    • Billet 4140 Steel
    • Heat Treated
  • Billet Extractor
    • Billet of 4140 Steel
    • Heat Treated
    • Shot Peened
    • Coating: Phosphate (Low Heat Input)
    • Extractor Insert
    • Viton O-Ring
  • Firing Pin
    • Billet 8640 Steel

LOWER RECEIVER

  • Platform: GEN3 Precision Machined 7075-t6 Aluminum Lower Receiver
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type III Anodizing with Cerakote Ceramic Coatings
  • Trigger: TYPE-A CCS 2-Stage Straight Trigger (3.5lb.) – S7 Tool Steel/Heat Treated
  • Extension: 6-Position Adjustable Buffer Tube – Carbine Length
  • End Plate:TYPE-A QD Single Point End Plate (4140 Pre-Hard)
  • Fire Selector: TYPE-A Ambi Billet 90°/70° Adjustable Short Throw Selector – Tool Steel
  • Magazine Release: TYPE-A Extended Billet Mag Release – Tool Steel
  • Lower Parts: Stainless Steel/Aluminum Detents & Springs

HANDGUARD/RAIL

  • Platform: Option
    • TYPE-A MK-13.375 Qaud Rail
  • Finish: Option
    • Black – MIL-A-8625, Type-III, Class 2
    • Color – Type-III Anodizing with Cerakote Ceramic Coatings

FURNITURE

  • Stock: B5 SOPMOD STOCK – COYOTE TAN
  • Grip: B5 P-GRIP – COYOTE TAN

ACCESSORIES (INCLUDED W/RIFLE)

  • Magazine: 30 Round Magazine
  • Soft Case: 36″ Single Rifle Case

Colors Available (*Shown in Armor Black & Midnight Bronze)

  • Magpul™ Olive Drab Green (H-232Q)
  • Magpul™ Flat Dark Earth (H-267Q)
  • Noveske™ Bazooka Green (H-189Q)
  • Tungsten (H-237Q)
  • SIG™ Dark Grey (H-210Q)
Barrel Length

Caliber

Gas System

Firearm Type
